Network Automation Ecosystem
A unified ecosystem of seven Rust and Python tools for network topology generation, modeling, protocol simulation, traffic analysis, and visualization.
Contents
Overview
The ecosystem is evolving from a collection of standalone tools into a Composable Network Toolchain. It follows the Linux philosophy—specialized tools that do one thing well—orchestrated by an IDE-level experience (The Workbench).
Core Architectural Tenets
- Standard-Agnostic Core: The Network Topology Engine (NTE) acts as a universal translator, capable of ingesting data from NetBox, ContainerLab, or custom sources.
- Logical-to-Physical Decoupling: We split Physical Topology from Logical Intent, decoupling engineering logic from specific vendor hardware.
- Hyper-Composable Entry Points: Pull from a Source of Truth $\rightarrow$ Visualize; Generate from scratch $\rightarrow$ Simulate; Capture live state $\rightarrow$ Analyze capacity.
The Composable Toolchain
┌─────────────────────────────────────────────────────────────────────────┐
│ Network Automation Workbench │
│ (FastAPI + React · Orchestration · Web UI) │
│ │
│ ┌──────────┐ ┌──────────────┐ ┌────────────┐ ┌──────────────────┐ │
│ │ Topology │ │ Modeling & │ │ Protocol │ │ Visualisation │ │
│ │ Editor │ │ Config │ │ Simulator │ │ Explorer │ │
│ └────┬─────┘ └──────┬───────┘ └─────┬──────┘ └────────┬─────────┘ │
└───────┼────────────────┼────────────────┼──────────────────┼────────────┘
│ │ │ │
subprocess Python API subprocess subprocess
│ │ │ │
┌───────▼────────┐ ┌─────▼──────────┐ ┌──▼───────────┐ ┌───▼──────────┐
│ topogen │ │ autonetkit │ │ netsim │ │ netvis │
│ │ │ │ │ │ │ │
│ 9 generators │ │ Pydantic models│ │ OSPF, IS-IS │ │ 5 layout │
│ Traffic matrix │ │ Query DSL │ │ BGP, MPLS │ │ algorithms │
│ Vendor naming │ │ Config gen │ │ SR, RSVP-TE │ │ SVG/PNG/PDF │
│ ContainerLab │ │ Blueprints │ │ L3VPN, BFD │ │ WASM target │
│ export │ │ Compiler │ │ gRPC daemon │ │ Edge bundling│
└───────┬────────┘ └──────┬────────┘ │ BMP telemetry│ └──────────────┘
│ │ └──────────────┘
│ ┌─────▼────────┐
│ │ NTE │
│ │ │
│ │ petgraph │
│ │ Polars DFs │
│ │ Query engine │
│ │ Pluggable │
│ │ datastores │
│ └──────────────┘
│
┌───────▼────────┐
│ netflowsim │
│ │
│ Queuing models │
│ Monte Carlo │
│ FIB path trace │
│ Rayon parallel │
└────────────────┘
Data flows top-to-bottom. The Workbench sits above all tools as the orchestration layer. autonetkit consumes NTE as a Rust dependency. topogen feeds generated topologies into autonetkit, netsim, netflowsim, and netvis. netsim validates routing behavior. netflowsim analyzes traffic performance. netvis renders the results.
The Tools
Topology Generator
v0.10 — Phase 21/24 · Full Details →
What It Is: A Rust library with Python bindings for generating realistic network topologies. Supports data center (fat-tree, leaf-spine), WAN/backbone (ring, mesh, hierarchical, POP), and random graph patterns (Barabasi-Albert, Watts-Strogatz). Includes traffic matrix generation using gravity models and ContainerLab output converters.
CLI Scrape — Network Device Output Parser
Phase 1 — Foundation · Full Details →
What It Is: Rust-based CLI scraping and parsing tool for network devices. TextFSM-compatible state machine parser with 10-50x faster execution than Python implementations. Includes interactive TUI debugger for template development and modern YAML/TOML template format.
Key Features:
- Full TextFSM compatibility (use existing ntc-templates library)
- Native Rust performance with parallel processing
- Interactive TUI debugger for template development
- Zero-copy parsing and pre-compiled regex patterns
Current Status: Phase 1 — defining lexer/parser for TextFSM files
Tech Stack: Rust, regex, ratatui
Network Configuration Parser
Phase 1 — Ingestion · Full Details →
What It Is: A framework for parsing legacy CLI configurations into vendor-agnostic models. Uses layout-aware PDF extraction (MinerU) to build a searchable knowledge base of vendor manuals in ChromaDB, enabling AI-assisted normalization of legacy state.
AutoNetkit
v1.8 — Shipped | v1.10 in progress · Full Details →
What It Is: A Python library for modeling and querying network topologies with type-safe Pydantic models and a Rust core. Expressive Python API backed by compiled graph algorithms (petgraph), with automatic configuration generation for multi-vendor network deployments (Cisco, Juniper, Arista, Nokia, SONiC).
Network Topology Engine
Stable · Full Details →
What It Is:
The Rust graph engine that powers the ecosystem. Provides native-speed topology operations exposed to Python through PyO3 bindings. Features a workspace of specialized crates for graph primitives (nte-graph), query execution (nte-query), and pluggable storage backends (Polars, DuckDB, Lite).
Network Simulator — Protocol Validation
v1.8 — Data Center Fabric & EVPN · Full Details →
What It Is: A deterministic, tick-based network simulator for rapid prototyping. Simulates OSPF, IS-IS, BGP, MPLS/LDP, and Segment Routing with packet-level accuracy. Enables sub-second validation of network convergence without the overhead of container-based emulation.
Network Traffic Simulator — Flow-Based Performance Analysis
Phase 3/5 — Active Development · Full Details →
What It Is: Flow-based network traffic simulator using analytic queuing models (M/M/1, M/D/1) and Monte Carlo simulations. Validates topologies and routing strategies against billions of flow iterations in seconds, providing massive-scale network performance analysis.
Network Visualization Engine
v1.3 — Embed Readiness & API Stability · Full Details →
What It Is: A Rust-based network topology layout and visualization engine. Renders complex multi-layer networks using advanced layout algorithms (force-directed, hierarchical, geographic, radial, isometric) with high-quality static output (SVG, PDF, PNG) and WASM targets.
Network Automation Workbench
v1.3 — Tool Integration & Interactive Workflows · Full Details →
What It Is: A platform that integrates the entire network automation ecosystem into a single workflow. Driven from YAML, a text-based TUI, or the web interface—upload topology YAML, visualize the network, run simulations, and analyze results without switching between tools.
AutoNetkit — The Foundation
PhD 2017 · Full Details →
What It Is: The original compiler-based network automation tool from my PhD research. Introduced declarative network design with the Whiteboard → Plan → Build transformation model. Integrated into Cisco’s VIRL platform for automated multi-vendor lab provisioning.
1. Rapid Prototyping
Generate a topology structure with topogen, validate that protocols converge in netsim in seconds, and visualize the resulting state with netvis.
2. Design-to-Deploy
Model a network declaratively in autonetkit, transform through protocol layers (ISIS, MPLS, EVPN), generate multi-vendor configurations, and validate the entire design in netsim before deploying to production or container labs.
3. Traffic Engineering
Analyze capacity at scale by computing forwarding paths from netsim FIBs, running Monte Carlo simulations in netflowsim against traffic demands, and visualizing link utilization heatmaps in netvis.
4. Interactive Exploration
Use the Workbench as a unified interface to edit topology YAML with live validation, trigger simulations, and attach to interactive device terminals via the netsim gRPC daemon.
